6G物联网晶体,QCM25-21AFT12-27.000,QVS无源晶振

产品简介

6G物联网晶体,QCM25-21AFT12-27.000,QVS无源晶振，尺寸5.0x7.0x1.3mm，频率27MHZ，美国进口QVS晶振，QVS石英晶体，无源晶振，四脚贴片晶振，石英SMD晶振，水晶振动子，无源贴片晶振，绿色环保晶振，7050mm无源晶体，27MHZ石英晶振，低损耗晶振，高性能晶振，高品质晶振，6G物联网专用晶振，无线设备晶振，便携式设备晶振，娱乐设备晶振，智能家居晶振，电影音系统晶振，电视机顶盒晶振，网络电子专用晶振，智能音响晶振，具有轻薄型高品质的特点.

贴片石英晶振产品很适合用于6G物联网，无线设备，便携式设备，娱乐设备，智能家居，电影音系统，电视机顶盒，网络电子，智能音响等领域.6G物联网晶体,QCM25-21AFT12-27.000,QVS无源晶振.

产品详情

6G物联网晶体,QCM25-21AFT12-27.000,QVS无源晶振 参数表

STANDARD SPECIFICATIONS
Frequency Range		27 MHz
Frequency Tolerance(25°C)		±50ppmStandard(seeCrystalPartNumberGuideformoredetails)
Resonance		Parallel@18pFStandard(seeCrystalPartNumberGuideformoredetails)
Shunt Capacitance(Co)		7pFmax
Aging		±5ppmmaxperyear
FrequencyStability over Operating Temperature		±100ppmStandard(seeCrystalPartNumberGuideformoredetails)
Drive Level		100μWto500μW
Operating Temperature Range		0°C ~+70°CStandard(see Crystal Part Number Guidefor moredetails)
Storage Temperature Range		-40°C~+85°C
EQUIVALENTSERIESRESISTANCE(E.S.R.)
Frequency Range	Mode ofOscillation		ESRMax.(Ω)
6MHz~7.99MHz	Fundamental		100
8MHz~9.99MHz	Fundamental		60
10MHz~13.99MHz	Fundamental		50
14MHz~19.99MHz	Fundamental		40
20MHz~40MHz	Fundamental		30
30MHz~150MHz	3rdOT		80
